Air handling unit Nordic S3 REL
(Change Variant)
Art. nr: 800121
GTIN: 7023678001219
Description
Flexit Nordic S3 air handling units have been developed to be energy efficient in Nordic climate. Easy connection option for kitchen hood via bypass. The ventilation unit has highly efficient rotary heat exchangers, with temperature efficiency up to 85%. All Nordic units are controlled as standard via the Flexit GO app and can be supplemented with various accessories, wireless or wired, eg. control panel, humidity sensor, pressure sensor for kitchen fan, CO2 sensor etc. The control system is prepared for local demand control. Cooling recovery is a standard feature in the Nordic series. With Flexit GO you can also activate the function free / night cooling. In case of high exhaust air humidity, the defrost function in Flexit GO can be activated, to ensure operation in cold climates.
- Energy efficient in Nordic climate
- Modern design
- Built-in humidity sensor
- Operational and service friendly
- Control through app and cloud services
- Very low sound levels to duct and surrounding
- Thechnical data
- Video
- Documentation
- Accessories
- Spare Parts
Performance | |||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
Air quantity max | 350 m³/h | ||||||||||
Fan speed, max | 3200 r/min | ||||||||||
Power | |||||||||||
Rated voltage | 230 V | ||||||||||
Frequency | 50 Hz | ||||||||||
Fuse size | 10.0 A | ||||||||||
Rated current, total | 3.4 A | ||||||||||
IP code | IP21 | ||||||||||
Rated power, total | 679 W | ||||||||||
Rated Power Fans | 2x83 W | ||||||||||
Rated Power el | 500 W | ||||||||||
Rated Power Rotormotor | 4.0 W | ||||||||||
Material and color | |||||||||||
Colour | White | ||||||||||
RAL-number | 9016 | ||||||||||
Gloss | 25 - 35 | ||||||||||
Ventilation | |||||||||||
Fan type | B-wheel | ||||||||||
Fan motor control | 0-10 V | ||||||||||
Automatic | Flexit GO | ||||||||||
Filter class, supply air | ePM1 55% (F7) | ||||||||||
Filter type | Compact filter | ||||||||||
Filter dim (bxhxd) | 166x272x48 mm | ||||||||||
Dimensions and weight | |||||||||||
Width (mm) | 599 mm | ||||||||||
Height (mm) | 777 mm | ||||||||||
Depth (mm) | 537 mm | ||||||||||
Weight | 56.0 kg | ||||||||||
Duct connection (Ø) | 125 mm | ||||||||||
Kitchen fan connection (Ø) | 125 mm |
- Information
- Guides
- Environment and energy
- Technical
- User manual
- User manual [DA]
- User manual (FI)
- Installation instructions
- Installation instructions [DA]
- Installation instructions (FI)
- Quick guide air handling unit and automation
- User manual Flexit GO (Nordic)
- User manual Flexit GO (Nordic) [FI]
- Installation instructions ventilation system with heat recovery
- Service report
- Planning and preparation work
Art. no:FlexitGO
FlexitGO
Art. no:119772
Control panel NordicPanel white
Art. no:121154
Control panel NordicPanel black
Art. no:116597
Filter set Nordic S2/S3
Art. no:116733
Access Point for Flexit GO
Art. no:116062
RH sensor CI77 wireless
Art. no:116098
Adapter CI75 Wireless
Art. no:116063
Control panel CI78 wireless
Art. no:116061
CO2 sensor CI76 wireless
Art. no:09390
Motion sensor SP450
Art. no:111410
Pressure guard kitchen duct w/cable
Art. no:118587
Powerline network adapter
Art. no:116793
Pressure sensor CI80
Art. no:116102
Pressure switch CI79 Wireless
Art. no:116405
Cable harness, Accessories Nordic
Art. no:111801
Closing air damper Ø125 w/spring
Art. no:116703
Heating coil water Ø125 Nordic
Art. no:116670
Heating coil water Ø160 A Nordic
Art. no:116671
Heating coil water Ø160 B Nordic
Art. no:120059
Cooling coil water Ø200
Art. no:14482
Closing air damper Ø160 w/spring
Art. no:116598
Duct cover Nordic S3/S2
Art. no:116599
Ceiling mounting plate Nordic S3/S2
Art. no:110955
Vibration damper kit 4pcs
Art. no:121037
Kitchen hood Tradition E/F
Art. no:110609
Kitchen hood Elegant E/F 60cm white
Art. no:110607
Kitchen hood Elegant E/F 60cm steel
Art. no:110604
Kitchen hood Vision-E/F 60cm steel
Art. no:110603
Kitchen hood Vision-E/F 90cm steel
Art. no:110608
Kitchen hood Elegant E/F 60cm black
Art. no:118690
Kitchen hood Facet-E/F ST
Art. no:118689
Kitchen hood Facet-E/F WH
Art. no:117298
Kitchen hood Flow E/F steel
Art. no:121077
Smoke detector for duct mounting
Art. no:13626
Kitchen hood Bistro-E/F
Art. no:13615
Kitchen hood Fondue-F
Art. no:116402
Control panel CI70 Spare
Art. no:121080
Renovation kit rotor module Nordic S3
Art. no:116408
Filter EMC FN 2010-10/06 Spare
Art. no:116400
Control Unit CU S Spare
Art. no:120296
CU-unit T11,T18 S Spare
Art. no:120298
CU-unit T11,T12,T18 S Spare
Art. no:120299
CU-unit T12 S Spare
Art. no:120300
CU-unit T1,T12 S Spare
Art. no:120307
CU-unit All Phoenix S Spare
Art. no:120742
CU unit Phoenix Humid. sens S Spare
Art. no:120914
RH and temp.sensor S2-S3-CL-W4-WH4 Spare
Art. no:120544
Rotor belt PJ3 Nordic S3-4 Spare
Art. no:116593
Fan compl Nordic S3
Art. no:120549
Rotor spring 2 pcs Nordic Spare
Art. no:120550
Rotor damper 4 pcs Nordic Spare
Art. no:116594
Rotor compl Nordic S3 spare
Art. no:112564
Choke coil 5 mH/3,3A Res
Art. no:119901
Spare part kit fan bearing
Art. no:116178
Rotor belt Nordic S3-4 Spare
Art. no:116595
Heating battery 500W S2/S3
Art. no:116496
Temperature sensor NTC
Art. no:116329
Thermostat OT 400mm Spare
Art. no:116330
Thermostat BT 400mm Spare
Art. no:120450
Termostat BT 80°C 400mm spare
Art. no:117771
Rotormotor Nordic/Econordic Spare
Art. no:116470
Surge suppressor with connector Sparepart
Art. no:118586
Network cable 5m Spare
Art. no:110853
Ties L=900mm Spare
Art. no:116403
Cable 2 pol CI 70 12m Spare
Art. no:117048
Extension connector 8-pole Spr
Art. no:116601
Wallbracket Nordic S2/S3
Art. no:116606
Door Nordic S2-S3 kpl Spare
Art. no:116605
Hinge compl. Nordic S2/S3
Art. no:116111
Door handle Nordic H/V
Art. no:117764
Brushlist complete 2,0 m spare
