Kitchen hood Bistro-M
Art. nr: 13627
GTIN: 7023670136278
Description
Bistro-M cooker hood is designed to be integrated into kitchen cabinet and similar. The cooker has 3 speeds. Equipped with a washable grease filter. The cooker hood is equipped with an adjustable damper for easy adjustment of basic ventilation. Lighting in the cooker hood is with 11W compact fluorescent lamps. The cover comes with 230V grounded socket with connector and cable with special contact for controlling the box fan.The cooker hood is easily mounted. NOTE that at least 45 cm distance between electric cooker and bottom edge of the cooker hood is required. If it is a gas stove, the distance should be at least 65 cm.
- Easy cleaning and maintenance
- LED lighting
- Easy mounting
- Thechnical data
- Documentation
- Spare Parts
| Speed l | Speed ll | Speed lll | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Air quantity max | 188 m³/h | 255 m³/h | 340 m³/h | ||||||||
| Air quantity | 200 m³/h | 275 m³/h | 385 m³/h | ||||||||
| Motor effect | 36 W | 39 W | 71 W | ||||||||
| Sound power dB(A) | 51 dB(A) | 57 dB(A) | 63 dB(A) | ||||||||
| Sound pressure dB(A) 1m | 46 dB(A) | 53 dB(A) | 58 dB(A) | ||||||||
| Power | |||||||||||
| Rated voltage | 230 V | ||||||||||
| Frequency | 50 Hz | ||||||||||
| Material and color | |||||||||||
| Colour | White | ||||||||||
| Lighting | |||||||||||
| Lighting | Compact fluorescent 11W G23 | ||||||||||
| Ventilation | |||||||||||
| Fume capture (%) v/m3/h | 98 % | ||||||||||
| Dimensions and weight | |||||||||||
| Weight | 5.8 kg | ||||||||||
| Duct connection (Ø) | 125 mm | ||||||||||
- Information
- Guides
- Environment and energy
- Technical
Art. no:114749
Lamp holder 2G7
Art. no:55731
Switch speed Bras/Bistr/Fond white
Art. no:55479
Light cover Bistro/Fondue
Art. no:55521
Switch for light Brass/Bist/Fond white
Art. no:101592
Switch for kitchen hood
Art. no:114751
Lighting ballast 4P 11W
Art. no:55732
Capacitor Brasserie/Bistro/Fondue
Art. no:114750
Lamp 4P 11W
Art. no:101826
Filter holder Bistro/Fondue
Art. no:13666
Carbon filter Fondue/Bistro
Art. no:55494
Filter polyester Bistro/Fondue
Art. no:55495
Grease filter Bistro/Fondue
Art. no:115276
Filter set Bistro/Fondue complete
