Kitchen hood Facet-M ST
(Change Variant)
Art. nr: 118694
GTIN: 7023671186944
Description
Facet-M is intended for installation under wall cabinets and provides a very good odour extraction. Equipped with a metal grease filter that can be washed in a washing machine. The hood has a damper in metal, electronic operation panel and good LED lighting with very long lifetime. Supplied with 230V earthed cable with plug. The hood is easy to install and has a "easy-clean" principle which makes maintenance easy. Necessary parts can easily be removed for cleaning. It requires min. 44 cm mounting height between electric oven and lower part of kitchen hood. For gas stoves, the distance must be increased to min. 65 cm.
- Very good odour reduction
- Washable metal grease filter
- LED lighting
- Electronic control panel
- Energy efficient EC motor
- Thechnical data
- Documentation
- Accessories
- Spare Parts
| Performance | |||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Air quantity | 332 m³/h | ||||||||||
| Power | |||||||||||
| Rated voltage | 230 V | ||||||||||
| Frequency | 50 Hz | ||||||||||
| Material and color | |||||||||||
| Colour | Stainless steel | ||||||||||
| Lighting | |||||||||||
| Lighting | LED 6,5W | ||||||||||
| Dimensions and weight | |||||||||||
| Width (mm) | 599 mm | ||||||||||
| Height (mm) | 60 mm | ||||||||||
| Depth (mm) | 490 mm | ||||||||||
| Weight | 6.7 kg | ||||||||||
| Duct connection (Ø) | 125 mm | ||||||||||
- Information
- Guides
- Environment and energy
- Technical
Art. no:119825
Corner facet white (pair)
Art. no:119826
Corner facet gray (pair)
Art. no:119796
Cable 3L 1,4m
Art. no:119800
Cover side support 60
Art. no:119830
Metal filter Facet M
Art. no:119817
Filter plate 1200 60 cm white
Art. no:119818
Filter plate 1200 60 cm gray
Art. no:119819
Filter lock 1200-series
Art. no:119822
Keypad 6 butt. str white hood
Art. no:119823
Keypad 6 butt. str gray hood
Art. no:119815
Ribbon cable 12V 18-POL L=500
Art. no:119798
LED lightning 6.5W
Art. no:119799
Cabel LED 430mm
Art. no:119812
Motor EC Facet
Art. no:119816
Impeller EC 1200
Art. no:119824
Shell air-transp. hood EC 1200
Art. no:119813
Cable protection EC 1200
Art. no:119821
Contr hood 21-1173A
Art. no:119831
Flange w/valve Facet-M
Art. no:119833
Screw kit Facet M
