Indoor Climate Heat Pump W4
Art. nr: 800502
GTIN: 7023678005026
Description
Flexit EcoNordic W4 is an indoor climate central with integrated functions for balanced ventilation and tap water production. The unit provides a healthy indoor climate and plenty of hot tapwater in a very energy efficient way. The product is especially suitable for houses with separate space heating solution and when replacing an old ventilation system and hot water boiler. The unit is built up from 4 modules to simplify handling and installation. All functions of the indoor climate central is controlled through the app Flexit GO.
- Environmental friendly refrigerant, CO2
- Very high efficiency
- Rotary heat exchanger
- Good efficiency down to -25°C
- Energy efficient hotwater
- All components placed indoor
- Technical data
- Video
- Documentation
- Accessories
- Spare Parts
| WH4 400V 3N~ | WH4 230V 3~ | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Rated Voltage | 400 V | 230 V | |||||||||
| Fuse size | 3x16 A(3x10 A) | 3x25 A(3x16 A) | |||||||||
| Rated current | 14,3 A(10,0 A) | 22,3 A(14,8 A) | |||||||||
| Total rated power | 6,4 (4,4kW) | ||||||||||
| Continuous flow through heater, capacity | 3 kW (1 kW) | ||||||||||
| Performance | |||||||||||
| Air flow max | 370 m3/h @ 100 Pa | ||||||||||
| Tap water profil (EN 16147) | XL | ||||||||||
| COP tap water (EN 16147) | 3.2 | ||||||||||
| Outgoing compressor capacity | 3.0 kW | ||||||||||
| Outgoing compressor capacity | |||||||||||
| Component efficiency (EN 308) | 84.0 % | ||||||||||
| Temperature efficiency | < 90 % | ||||||||||
| Hot water | |||||||||||
| Heater volume | 197.0 | ||||||||||
| Nominal operating pressure | 0,45/4,5 MPa/bar | ||||||||||
| Max. operating pressure hot water | 0,7/7 MPa/bar | ||||||||||
| Water temperature | 5–65 °C (Legionella: 75 °C) | ||||||||||
| Minimum distance to combustible surfaces | No requirement | ||||||||||
| Power | |||||||||||
| IP code | IP21 | ||||||||||
| Sound | |||||||||||
| Sound power dB(A) | 52.0 dB | ||||||||||
| Ventilation | |||||||||||
| Fan type | B-wheel | ||||||||||
| Fan motor control | 0-10 V | ||||||||||
| Automatic | Flexit GO | ||||||||||
| Filter class, supply air | ePM1 55% (F7) | ||||||||||
| Heat pump | |||||||||||
| Refrigerant | CO2 (0,5 kg) | ||||||||||
| GWP | 1 | ||||||||||
| Duct connection heat pump | 200 mm | ||||||||||
| Max. operating pressure heat pump | 14/140 MPa/bar | ||||||||||
| Outdoor air temperature | min. -25°C | ||||||||||
| Inverter control | Yes | ||||||||||
| Installation | |||||||||||
| Position | Technical room/cupboard | ||||||||||
| Ambient temperature | 3 - None °C | ||||||||||
| Dimensions and weight | |||||||||||
| Width (mm) | 1198 mm | ||||||||||
| Height (mm) | 1900 mm | ||||||||||
| Depth (mm) | 650 mm | ||||||||||
| Weight | 232.0 kg | ||||||||||
| Duct connection (Ø) | 160 mm | ||||||||||
| Tank module | 65 kg (59 kg weight without door) | ||||||||||
| Ventilation module | 84 kg (76 kg weight without door) | ||||||||||
| Heat pump module | 71 kg (65 kg weight without door) | ||||||||||
| Installations module | 12.0 kg | ||||||||||
