Single room ventilator Roomie Dual W V2W
(Change Variant)
Art. nr: 120879
GTIN: 7023671208790
Description
Single room ventilator Roomie Dual WiFi V2 provides balanced ventilation with heat recovery in parts of the home or in individual rooms. It has two fans that ensure continuous supply and exhaust air.
The heat is recovered from the exhaust air in a ceramic heat recovery unit which simultaneously provides tempered and filtered supply air. The ventilators are used individually, in pairs or as a network depending on the area. Integrated WiFi makes it easy to connect several ventilators that communicate wirelessly. Simple start-up, control and connection with a mobile app. All models are supplied with a connected power cable and plug. Outer hood in painted grey aluminium. Options for external sensors. Can be connected to smart house systems.
- Balanced ventilation with heat recovery
- Fresh, filtered and tempered supply air
- Energy efficient, heat recovery up to 85%
- Easy control and connection with app
- Easy installation, with connected power cable
- Technical data
- Video
- Documentation
- Accessories
- Spare Parts
Speed 1 | Speed 2 | Speed 3 | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
Airflow heat recovery mode | 10.0 m³/h | 20.0 m³/h | 30.0 m³/h | ||||||||
Airflow ventilation mode | 10.0 m³/h | 20.0 m³/h | 30.0 m³/h | ||||||||
Power consumption | 2.17 W | 3.66 W | 6.62 W | ||||||||
Current | 0.026 A | 0.039 A | 0.066 A | ||||||||
Sound pressure Lp(A) 3m | 17 dB | 29 dB | 38 dB | ||||||||
Sound power Lw(A) | 34 dB | 46 dB | 55 dB | ||||||||
Airflow exhaust mode | 60.0 m³/h | ||||||||||
Power | |||||||||||
Voltage | 100 - 240 V | ||||||||||
Frequency | 50 - 60 Hz | ||||||||||
IP code | IP24 | ||||||||||
Insulation Class | II | ||||||||||
Material and color | |||||||||||
Colour | White | ||||||||||
Sound | |||||||||||
Sound absorption Dn,e,w (C;Ctr) | 42 (-1;-3) | ||||||||||
Ventilation | |||||||||||
Filter class | G3 | ||||||||||
Wifi | |||||||||||
Wifi standard | IEFE 802.11 b/g/n | ||||||||||
Frequency band | 2.4 GHz | ||||||||||
Transmission power [mW] (dBm) | 100 (+20) | ||||||||||
Network | DHCP | ||||||||||
WLAN safety | WPA, WPA2 | ||||||||||
Installation | |||||||||||
Position | Yttervegg | ||||||||||
Ambient temperature | -15 - 40 °C | ||||||||||
Dimensions and weight | |||||||||||
Weight | 6.0 kg | ||||||||||
Dimension (Ø) | 160 mm | ||||||||||
Wall thickness | 280 - 500 mm |
- Information
- Guides
- Environment and energy
- Technical
Speed 1 | Speed 2 | Speed 3 | |||||||||
---|---|---|---|---|---|---|---|---|---|---|---|
Airflow heat recovery mode | 10.0 m³/h | 20.0 m³/h | 30.0 m³/h | ||||||||
Airflow ventilation mode | 10.0 m³/h | 20.0 m³/h | 30.0 m³/h | ||||||||
Power consumption | 2.17 W | 3.66 W | 6.62 W | ||||||||
Current | 0.026 A | 0.039 A | 0.066 A | ||||||||
Sound pressure Lp(A) 3m | 17 dB | 29 dB | 38 dB | ||||||||
Sound power Lw(A) | 34 dB | 46 dB | 55 dB | ||||||||
Airflow exhaust mode | 60.0 m³/h | ||||||||||
Power | |||||||||||
Voltage | 100 - 240 V | ||||||||||
Frequency | 50 - 60 Hz | ||||||||||
IP code | IP24 | ||||||||||
Insulation Class | II | ||||||||||
Material and color | |||||||||||
Colour | White | ||||||||||
Sound | |||||||||||
Sound absorption Dn,e,w (C;Ctr) | 42 (-1;-3) | ||||||||||
Ventilation | |||||||||||
Filter class | G3 | ||||||||||
Wifi | |||||||||||
Wifi standard | IEFE 802.11 b/g/n | ||||||||||
Frequency band | 2.4 GHz | ||||||||||
Transmission power [mW] (dBm) | 100 (+20) | ||||||||||
Network | DHCP | ||||||||||
WLAN safety | WPA, WPA2 | ||||||||||
Installation | |||||||||||
Position | Yttervegg | ||||||||||
Ambient temperature | -15 - 40 °C | ||||||||||
Dimensions and weight | |||||||||||
Weight | 6.0 kg | ||||||||||
Dimension (Ø) | 160 mm | ||||||||||
Wall thickness | 280 - 500 mm |
