Air handling unit Nordic S7 SW RER (Change Variant)

Art. nr: 800140

GTIN: 7023678001400

Flexit Nordic S7 SW features patented rotating heat exchanger technology and the Stage Wheel, providing the most energy-efficient ventilation unit on the market with up to 90% thermal efficiency. Low energy consumption and local demand control earn it an A+ eco-design label. Designed for single-family homes and small commercial buildings in Nordic climates, it operates up to 700 m³/h and is ideal for homes up to 450 m². This cabinet unit is suitable for wall and floor mounting and includes adjustable vibration-dampening feet. It can be installed in both cold and warm rooms. Controlled via the Flexit GO app, it supports various accessories, such as a control panel, humidity sensor, and CO2 sensor. Cooling recovery is standard.

The most energy-efficient rotating HEX
Eco-design label A+ with local demand control
Vibration-dampening feet
Built-in humidity sensor
Very low noise level to the duct and surround
Control via app and cloud services

New

Technical data
Documentation
Accessories
Spare Parts


Rated power, total			1855 W
Performance
Air flow max			700 m³/h
Fan speed, max			4350 r/min
Power
Rated voltage			230 V
Frequency			50 Hz
Fuse size			10.0 A
Rated current, total			8.1 A
IP code			IP 21
Rated Power Fans			2X170W
Rated Power el			1500 W
Rated Power Rotormotor			4.0 W
Material and color
Colour			White
RAL-number			9016
Gloss			25 - 35
Ventilation
Fan type			B-wheel
Fan motor control			0-10 V
Automatic			Flexit GO
Filter class, supply air			ePM1 70% (F8)
Filter class, extract air			ePM1 55% (F7)
Filter type			Compact filter
Filter dim (bxhxd)			300x269x96
Motor type			EC
Dimensions and weight
Width (mm)			1000 mm
Height (mm)			857 mm
Depth (mm)			600 mm
Weight			82.5 kg
Weight doors			11
Weight rotormodule			15.9 kg
Duct connection (Ø)			200 mm
Kitchen fan connection (Ø)			125 mm

Information
Guides
Environment and energy
Technical
O&M

Art. no:121258

Duct cover Nordic S7

Art. no:121594

Filter set F7/F8 Nordic S7

Art. no:121251

Filter set F7/F7 Nordic S7

Art. no:121179

Heating coil water Ø200 A Nordic

Art. no:121180

Heating coil water Ø200 B Nordic

Art. no:120059

Cooling coil water Ø200

Art. no:14481

Closing air damper Ø200 w/spring

Art. no:119772

Control panel NordicPanel white

Art. no:121154

Control panel NordicPanel black

Art. no:116063

Control panel CI78 wireless

Art. no:116098

Adapter CI75 Wireless

Art. no:116061

CO2 sensor CI76 wireless

Art. no:116062

RH sensor CI77 wireless

Art. no:116102

Pressure switch CI79 Wireless

Art. no:09390

Motion sensor SP450

Art. no:116793

Pressure sensor CI80

Art. no:111410

Pressure guard kitchen duct w/cable

Art. no:110609

Kitchen hood Elegant E/F 60cm white

Art. no:13616

Kitchen hood Fondue-E

Art. no:110607

Kitchen hood Elegant E/F 60cm steel

Art. no:110604

Kitchen hood Vision-E/F 60cm steel

Art. no:110603

Kitchen hood Vision-E/F 90cm steel

Art. no:110608

Kitchen hood Elegant E/F 60cm black

Art. no:118690

Kitchen hood Facet-E/F ST

Art. no:118689

Kitchen hood Facet-E/F WH

Art. no:13626

Kitchen hood Bistro-E/F

Art. no:13615

Kitchen hood Fondue-F

Art. no:121077

Smoke detector for duct mounting

Art. no:117298

Kitchen hood Flow E/F steel

Art. no:118587

Powerline network adapter

Art. no:116405

Cable harness, Accessories Nordic

Art. no:116733

Access Point for Flexit GO

Art. no:121541

Control Unit CU L6/S7 Spare

Art. no:121537

Rotor compl. Nordic S7 Spare

Art. no:121545

Hinge compl. Nordic S7

Art. no:121539

Door Nordic S7 spare

Art. no:121536

Rotor belt PJ3 Nordic S7 Spare

Art. no:121544

Wallbracket Nordic S7

Art. no:121540

Damper feets kit 4pcs L6/S7

Art. no:121542

RH and temp.sensor S7 Spare

Art. no:121543

Fan compl. Nordic L6/S7

Art. no:121538

Heating battery 1500W S7

Art. no:116496

Temperature sensor NTC

Art. no:119901

Spare part kit fan bearing

Art. no:112564

Choke coil 5 mH/3,3A Res

Art. no:118586

Network cable 5m Spare

Art. no:116408

Filter EMC FN 2010-10/06 Spare

Art. no:117048

Extension connector 8-pole Spr

Art. no:117771

Rotormotor Nordic/Econordic Spare

Art. no:116470

Surge suppressor with connector Sparepart

Art. no:116111

Door handle Nordic H/V

Art. no:117764

Brushlist complete 2,0 m spare

Art. no:120549

Rotor spring 2 pcs Nordic Spare

Art. no:120450

Termostat BT 80°C 400mm spare

Art. no:116329

Thermostat OT 400mm Spare

Art. no:120550

Rotor damper 4 pcs Nordic Spare

Art. no:116406

Wiring harness el S4

Art. no:110853

Ties L=900mm Spare


Rated power, total			1855 W
Performance
Air flow max			700 m³/h
Fan speed, max			4350 r/min
Power
Rated voltage			230 V
Frequency			50 Hz
Fuse size			10.0 A
Rated current, total			8.1 A
IP code			IP 21
Rated Power Fans			2X170W
Rated Power el			1500 W
Rated Power Rotormotor			4.0 W
Material and color
Colour			White
RAL-number			9016
Gloss			25 - 35
Ventilation
Fan type			B-wheel
Fan motor control			0-10 V
Automatic			Flexit GO
Filter class, supply air			ePM1 70% (F8)
Filter class, extract air			ePM1 55% (F7)
Filter type			Compact filter
Filter dim (bxhxd)			300x269x96
Motor type			EC
Dimensions and weight
Width (mm)			1000 mm
Height (mm)			857 mm
Depth (mm)			600 mm
Weight			82.5 kg
Weight doors			11
Weight rotormodule			15.9 kg
Duct connection (Ø)			200 mm
Kitchen fan connection (Ø)			125 mm
